Technical Information
5
W1113, W1119, W1203, W1213 & W1215 Clothes Washers
C Technical Data
Frontloader
Version
Spaceframe construction
Fascia panel version Light-touch buttons
Door lock Electromagnetic release
Drum Honeycomb drum
Casing
Drum diameter 480 mm (18.9 in.)
Maximum load, dry
laundry
5 Kg (11.02 lbs) – W1113 and W1119
6 Kg (13.23 lbs)– W1203, W1213 and
W1215
Suds
container
Drum opening
dimensions
300 mm (11.81 in)
Cold water connection: Water Path
Control Unit and single solenoid valve
Water intake
Hot water connection: Single solenoid
valve
Water path
Drainage 240VAC Drain Pump
Belt drive
Ribbed drive belt, motor spindle
diameter: 27.5 mm (1.08 in.), axis-
center difference: 366 mm (14.41 in.),
gearing (no. of motor rotations for one
drum rotation): 10.6
Electric motor
DC series-wound motor
Control Pulse-width modulated (PWM) DC
Drive
Speed monitoring Tachogenerator
Table C-1: Technical Data (continued on Table C-2)
