Technical Information
31
W1113, W1119, W1203, W1213 & W1215 Clothes Washers
4.2 Water Path Control System - Removal
1. Refer to Figure 040-2.
2. Disconnect the Electrical Connections.
3. Remove the screws from the Dispenser Assembly top cover.
4. Remove the retaining clips (1), from the top of the Dispenser
Assembly. Lift the top cover and remove it to the rear.
5. Remove the Water Path Control System.
Figure 040-2: Water Path Control System
