Technical Information
13
W1113, W1119, W1203, W1213 & W1215 Clothes Washers
4.4 Side Panel - Removal
1. Remove the Lid (010 4.1).
2. Remove the Front Panel (010 4.3).
3. Remove the three screws from the rear edges of each panel,
Figure 010-1.
Warning!
The 2 middle screws / washers provide the grounding for the
side panels – ensure the screws are secured during re-
assembly.
4. Remove the three screws from the top edge of each panel.
5. Remove the three screws from the front edge of each panel.
6. Pull out the top of the side panel slightly.
7. Push down the panel to unclip it from the bottom of the frame.
Note
To refit the side panel, support the panel while holding against
the underside of the bottom frame at an angle. Lift the panel into
position and align the top edge of the panel to the frame.
