Miele W1113 - Non-Return Valve Removal

Technical Information
36
W1113, W1119, W1203, W1213 & W1215 Clothes Washers
4.2 Non-return Valve - Removal
1. Remove the Left Side Panel (010 4.4)
2. Remove the Drain Hose from the Non-Return Valve.
3. Remove the retaining screw from the Rear Panel.
4. Remove the Vent Hose to the filter (from the Non-Return Valve).
5. Pull out the Non-Return Valve retainer from the rear panel.
6. Push the entire Non-Return Valve Assembly downwards and
remove it to the side.
