OM-245 849 Page 6
2-2. WEEE Symbol (For Products Sold Within The EU)
Do not discard product (where ap-
plicable) with general waste.
Reuse or recycle Waste Electrical
and Electronic Equipment (WEEE)
by disposing at a designated collec-
tion facility.
Contact your local recycling office
or your local distributor for further
information.
2-3. Symbols And Definitions
A
Amperes
I
Output/On
Gas Tungsten Arc
Welding (GTAW)
Shielded Metal Arc
Welding (SMAW)
V
Volts Voltage Input
3 Phase Static Frequency
Converter-Transformer-Rectifier
Voltage Output Off Remote
Lift-Arc Start
(GTAW)
Protective Earth
(Ground)
Process High Temperature
Increase/Decrease
Of Quantity
On Percent Positive Negative
Alternating
Current
Hz
Hertz Arc Force (DIG)
I
2
Rated Welding
Current
X
Duty Cycle Direct Current Line Connection
U
2
Conventional Load
Voltage
U
1
Primary Voltage
IP
Degree Of
Protection
I
1max
Rated Maximum
Supply Current
I
1eff
Maximum Effective
Supply Current
U
0
Rated No Load
Voltage (Average)
