SECTION 5 − OPERATION
5-1. Controls
356.029.207-A / 802 889
6
Green on nameplate indicates a TIG func-
tion, Gray indicates a Stick function.
1 Process Controls
See Section 5-2.
2 Amperage Control
See Section 5-5.
3 DIG Control
See Section 5-6.
4 High Temperature Shutdown Light
See Section 3-4.
5 Power On Light
The power on light turns on when power is
turned on.
6 Power Switch
Use switch to turn unit and indicator light
On/Off.
