Millipore Milli-Q Integral 3 - Consumables; Flow diagram

22
Consumables
Flow diagram
The water flow through a Milli-Q System is shown here in a flow diagram.
The various consumables are described below.
Item Description Item Description
A Progard Pack D Quantum Cartridge
B UV 254 nm Lamp E
A10
®
TOC Monitor
Lamp
C UV 185 nm Lamp F POD Pak
Continued on next page
A
B
C
D
E
F
