SETTING THE NUMBER CUT FUNCTION
[MODE SET] > [MULTI-PASS]
The same data can be cut as many as five times by changing the pressure values. This allows the
device to efficiently cut a work that cannot be thoroughly cut out by performing cutting once.
However, the number cut function is disabled in unit B.
A period of time required to judge a separating point between pieces of data can also be specified.
The device starts the multi-pass unless the device receives next piece of data within the specified
period of time.
Set values
Period of time required for judgment: Off, 5, 15, 30, 45, 60 Sec
PRESS 1: Off, 300 to 5000 g (in increments of 50 g)
PRESS 2: Off, 300 to 5000 g (in increments of 50 g)
PRESS 3: Off, 300 to 5000 g (in increments of 50 g)
PRESS 4: Off, 300 to 5000 g (in increments of 50 g)
PRESS 5: Off, 300 to 5000 g (in increments of 50 g)
*1: In the RC model, 1000 g to 5000 g.
In the RT model, 300 g to 1500 g.
If the PRESS 1 to PRESS 5 are set to “off,” the device will not perform the multi-pass.
1 Press the
PAGE
+
key several times
until the LCD indicates page 3 of the
LOCAL MENU.
2 Select the [MODE SET].
3 Select the [MULTI-PASS].
4 Establish the [JUDGMENT TIME].
Off, 5, 15, 30, 45, 60 (s)
[ LOCAL ] 1 / 4
TOOL SELECT ———>
CONDITION ———>
TEST CUT ———>
[ LOCAL ] 3 / 4
INTERFACE ———>
MODE SET ———>
SELF TEST ———>
< MODE SET > 1 / 5
Z STROKE 7 mm >
MULTI–PASS ———>
VACUUM AutoOFF>
< MULTI–PASS > 1 / 2
JUDGMNT TIME 15 >
PRESS 1 OFF >
PRESS 2 OFF >
PAGE
+
F1
+
F2
+
F2
+
