— 2.27 —
SELECTING A TOOL [TOOL SELECT]
Now, select a head and a tool to be used in the cases described below.
• In the case where the pen number cannot be specified on the CAD.
• In the case where [TEST CUT] function or [SELF TEST] function is executed on the device
itself
• In the case where the [CMD SW] is set to “invalid” in the OPERATION mode
Tools that can be separetely set for each head are as follows:
Head AB C
Tool Pen / Reciprocal Rollers 1 to 4 / Cutters 1 to 2
Model name Swievel blade Cutters 1 to 2 R. cutters 1 to 2
RC-head model O O — O
RT-head model O O O —
The following describes how to set the head from A to B and the tool to cutter 2.
1 Press the
PAGE
+
key several times un-
til the LCD indicates page 3 of the LO-
CAL MENU.
2 Select the [TOOL SELECT].
3 Select the head to be used in the op-
eration
Every time the
F1
+
key is pressed, the
selected head will change.
A, B, C
Heads that can be selected differ with the
head models.
[ LOCAL ] 1 / 4
TOOL SELECT ———>
CONDITION ———>
TEST CUT ———>
[ LOCAL ] 1 / 4
TOOL SELECT ———>
CONDITION ———>
TEST CUT ———>
PAGE
+
F1
+
< TOOL SELECT > 1 / 1
HEAD ∗A >
TOOL ∗PEN >
To Next Page
