MIMAKI CF-0912 - Blower Installation Area

— 1.3 —
Installation area (CF-1215)
Installation area (CF-1218)
Blower installation area
Set the blower under the main unit.
• The exhaust temperature reaches high levels. Do not place eas-
ily flammable materials in the direction of the exhaust.
• The exhaust temperature can rise as high as 140˚C. Since the
temperature remains high even after the blower is stopped, be
careful not to get burned.
1000 mm
4057 mm
1000 mm
1000 mm
1000 mm
3895 mm
1000 mm
1000 mm
1000 mm
1000 mm
4357 mm
3895 mm
