— A.15 —
D. SPECIFICATIONS
Basic specifications
Type CF-0907 CF-0912 CF-1215 CF-1218
Effective stroke X axis 700 1200 1500 1800
Y axis 900 1200
Driving method X, Y, Z, θ 4-axis DC software servo
Maximum speed 50 cm/s
Maximum acceleration 0.5 G
Mechanical resolution X axis : 0.00234375 mm, Y axis : 0.003125 mm, θ axis : 0.05625°
Command resolution 0.025 mm / 0.01 mm (switchable on operation panel)
Range accuracy ±0.1 mm or ±0.1% of travel distance, whichever is largest
Repeat accuracy ±0.1 mm
Origin reproducibility ±0.1 mm
Perpendicular accuracy 0.6 mm 0.7 mm 0.9 mm
Work securing method Vacuum suction by blower
Maximum set work thickness 20 mm
*2
Settable work weight 70 kg max. (point load)
Receiving buffer capacity 1MB
Command MGL-IIc4 (MGL-IIc supported)
*3
Interface RS-232C
Packing configuration Main unit and pedestal separated and packed in one box; blower packed in separate box
Width 1257 1757 2057 2357
Depth 1595 1895
Height 1100 (except cable guide)
Cutting panel surface height Approx. 770
Main unit weight 120 140 165 180
Operating environment 5 to 40°C, 35 to 75% (Rh), no condensation
Input power supply Main unit : 50/60 Hz 100V
Blower
*4
: 50/60 Hz 100V
Power consumption Main unit : 300VA
Blower : 0.51KW (50Hz) 0.7KW (60Hz)
Static ac-
curacy
*1
External
dimen-
sions
*1. This is the accuracy for pen writing with almost no load. The guaranteed temperature range is 20 to 25°C.
*2. This is the maximum thickness of works that can be set. This value differs from the maximum thickness that can be cut.
*3. This is a dedicated HP-GL command.
*4. A rush current flows when the blower is switched on. The capacitance is prescribed elsewhere.
