— 2.25 —
ATTACHING THE WORK HOLDER
The work holder prevents the work from moving up after it is cut.
The work holder can be used for works of up to 10 mm thick.
The work holder does not support thickness greater than 10 mm.
When using soft works (sponges, etc.), do not use the work holder. The work holder
is designed to hold works such as corrugated fiberboard.
1 Remove the fixing screw of unit B.
To loosen the screw, turn it counterclock-
wise.
Work holder
