MIMAKI CF-0912 User Manual

— A.9 —
MODE SET Z STROKE 7, 4 (mm) MULTI-PASS OFF, 5, 15, 30, 45, 60 (Sec)
PRESS 1st OFF, 300 ~ 1000 (g)
MULTI-PASS PRESS 2nd OFF, 300 ~ 1000 (g)
PRESS 3rd OFF, 300 ~ 1000 (g)
VACUUM AutoOFF, PanelOFF PRESS 4th OFF, 300 ~ 1000 (g)
PRESS 5th OFF, 300 ~ 1000 (g)
AUTO VIEW OFF, 1s, 3s
DUMMY CUT OFF, ON
ONE-STROKE OFF, ON, SORT
ROTATE +90, –90 (°) MGL-IIC3
G (M)_0.001 G CODE
COMMAND G (M)_1.0
G (I)_0.001
3/4 CMD (COMMAND SW) VALID, INVALID G (I)_1.0
OH UNIT INITIAL VALUE,
SET VALUE
ORIGIN CENTER,
LOWER LEFT
GDP 0.025, 0.010 (mm)
PEN ASSIGN
UNIT MM, INCH
SELF TEST PATTERN CUT 1
PATTERN CUT 2
DATA DUMP (ASCII)
SAMPLE 0.5 mm
SAMPLE 1.0 mm
SAMPLE 1.5 mm
CIRCLE R=3
CIRCLE R=5
CIRCLE R=10
CIRCLE R=20
CIRCLE R=50
CIRCLE R=100
PARAMETER DUMP
CUT AREA LL, UR
4/4 AXIS ALIGN
TOOL B TOOL ADJUST
ADJUST
ROLLER ADJUST
CIRCLE θ CORRECTION
PEN 1 ~ 6 HEAD TOOL PEN
TOOL SWIEVEL
HEAD TOOL θ CUTTER 1
θ CUTTER 2
HEAD TOOL ROLLER 1
ROLLER 2
ROLLER 3
ROLLER 4
R. CUTTER 1
R. CUTTER 2
A LENG (LENGTH) –4.00 ~ +4.00
B –4.00 ~ +4.00
TEST PATTERN
CUTTER θ –4500 ~ +4500
PATTERN NO. 1, 2
TEST PATTERN
CUTTER X +33.00 ~ –41.00
CUTTER Y +50.00 ~ +58.00
TEST PATTERN
A LENG (LENGTH) –4.00 ~ +4.00
B –4.00 ~ +4.00
TEST PATTERN
ROLLER θ –4500 ~ +4500
PATTERN NO. 1
TEST PATTERN
ROLLER X +33.00 ~ –41.00
ROLLER Y +32.00 ~ +44.00
TEST PATTERN
R < 5 –20° ~ +20°
5 <= R < 10 –20° ~ +20°
TEST PATTERN
10 <= R < 20 –9.8° ~ +9.8°
20 <= R < 50 –9.8° ~ +9.8°
TEST PATTERN
50 <= R < 100 –9.8° ~ +9.8°
R >= 100 –9.8° ~ +9.8°
TEST PATTERN
