4-5
4
Extended Functions – Cutting –
Cutting out Data with Register Marks
If you create register marks on an output image, the cutter unit detects these marks and cuts the image out
automatically following these marks. This helps you to make stickers, etc.
This section describes how to cut the printed medium.
Refer to P.4-10 for the combined operation of print & cut.
There are following two types of register marks.
Flow of Cutting Data with Register Marks
Entering Register Mark Detection Mode
1
Press the key in LOCAL.
• The machine enters the register mark detection mode.
• Use the TP4 when performing trapezium correction to correct the uneven medium-feeding rate caused
by the difference in the diameter between the right and left grid rollers. If the trapezium correction is to
be omitted, there is no need to set the TP4. In that case, however, cutting distortion will increase.
• When the registration detection is set to OFF, the machine doesn't enter registration mode. ( P.4-11)
• If this key is pressed while various settings are being configured, the input value may be canceled or the
active set item may be returned to the previous set item.
TP1
TP2
TP3
TP4
TP1
TP2
TP3
TP4
Register mark: Type 1 Register mark: Type 2
Add register marks on the image with which you want to
make a sticker, etc., and then print the image with
register marks on a medium.
Set the printed medium in CJV30.
Send the cut-target image from the computer
for cutting.
There are some conditions for creating the
register marks.
See pages P.4-6 through P.4-10.
Set it referring to P.2-15.
In case it is not successfully cut,
•Confirm the response of the register mark
sensor. ( P.4-17)
•Confirm the position of the Light Pointer.
(P.4-20)
•Adjust the sensitivity of the register mark
sensor. ( P.4-21)
