4-32
Cutting out Data without Register Marks
To print & cut the data without register marks, adjust the misalignment between a printed image and the cutting
line (P/C Adjust).
The P/C Adjust has the following items.
Example of the P/C Adjust
This can be set for the conditions of each tool separately. Set it according to the purpose of use.
Setting the P/C ORIGIN OFFSET
Adjust the misalignment between the print origin and the cutting origin.
According to the scanning speed in the Y direction, 540dpi and 720dpi has the different ink drop positions while
printing. Adjust with the resolution you want to print.
1
Set a PVC medium ( P.2-15), and attach the eccentric cutter for cutting
(P.2-10).
2
Press the key in LOCAL to select the cutting
mode.
3
Press the key.
• Before adjusting, set a PVC medium and attach the provided eccentric cutter for cutting.
• Before setting in this section, perform “Setting Media Correction” ( P.3-8) in print mode.
• Even if adjusting in this section, some data may be slightly misaligned depending on the print mode,
medium features, the pinch roller setting or the other causes. If so, adjust again.
• This function is valid when the firmware Ver.2.10 or later is installed.
Set item Overview
P/C ORIGIN OFFSET Adjusts the misalignment between the print origin and the cutting origin.
P/C SCALE ADJUST
Adjusts the scale to apply cutting to the correction value of the media-feeding set on the media
correction ( P.3-8).
When using the tool condition [CUT1] to cut the data with the register mark detection. P/C Adjust is not needed.
When using the tool condition [CUT2] to print & cut the data without register marks. Perform P/C Adjust.
When using the tool condition [CUT3] only to cut the color medium or the like. P/C Adjust is not needed.
When using the tool condition [PEN] only to draw with a pen. P/C Adjust is not needed.
• This machine stores an adjustment value of either 540dpi or 720dpi. Select the resolution of the printing
to be performed after adjustment.
• You can set the P/C origin offset for each tool condition.
• When you cut by using two and more tool conditions ([CUT1] and [HALF] etc.) within the same data, set
the same adjusting value for each tool condition. If you cut by tool condition with different adjusting
value, misalignment may occur.
• When you set the same setting for two and more tool conditions, it is not required to print & cut the
adjusting pattern in the second tool condition setting. After performing the Step 8, press key to
enter the P/C origin offset value.
To Next Page
