8-3
Main Body Specifications
8
Appendix
Repetition Accuracy Conditions
State of the Plotter
• Clamping pressure: Strong
State of How a Medium Should Be Set
• The left and right margins of the medium must be 20 mm wide or more.
• The medium on the front side must not be warped or lifted.
• The medium and the backing sheet must not be separated (no air bubbles between them) because of the bend of
the medium.
• The medium must be set properly by the medium feeding function.
• When the medium is a roll medium, it must not be wound up loosely. (The surface of both ends of the medium
must have no steps.)
Cutting Speed
• 30 cm/s or less (when the attached cutter is used)
Data to Be Cut
• Test pattern for maintenance (ten continuous reciprocating motions in the longitudinal direction)
• The medium and the backing sheet must not be separated (no air bubbles between them) because of the extreme
bend of the medium caused while it is cut.
Command MGL- II c2
Program step 25 m / 10 m
*1. The maximum speed may be limited, depending on the size of a used medium. In addition, the cutting section does not
operate with both speed and acceleration being at the maximum.
*2. Use one with a diameter of 8 to 9 whose clamped part has no protrusion or taper. In addition, because the position of the
pen point changes, depending on the types of pens, no good image quality can be ensured.
*3. This conforms with our specified sheet.
*4. When a blade dedicated for fluorescent sheets (SPB-0007) or a blade dedicated for reflecting sheets (SPB-0006) is used
*5. For repetition accuracy, see the lower part of this page.
Item CJV30-60 CJV30-100 CJV30-130 CJV30-160
To Next Page
