6-16
Cleaning the Ink Head and the Area around It
Because the ink head employs a very precise mechanism, due care needs to be taken when it is cleaned.
Using a clean stick, etc., rub off gelatinous ink or dust that may stick to the lower part of the slider and the area
around the ink head. In doing so, never rub the nozzles of the head.
1
Press the key in LOCAL to select the
printing mode.
2
Select [ CR.MAINTENANCE ] of the maintenance menu.
(1) Press the key.
(2) Press to select [ MAINTENANCE ] and press the key.
(3) Press to select [ CR.MAINTENANCE ] and press the
key.
3
Remove the maintenance cover.
(1) Turn the two screws that fix the maintenance cover
counterclockwise to remove them.
(2) Remove the maintenance cover.
4
Press the key.
5
Press the key.
• Carriage will move to the left end of this device.
Tools needed for cleaning
• Clean stick • Gloves • Goggles
• Be sure to wear the attached goggles and gloves when cleaning the area around the ink head.
Otherwise, you may get ink in your eyes.
• The ink contains organic solvent. If you get the ink on your skin or in your eyes, wash it away with plenty
of water immediately.
• You can move the carriage manually, however, if you connect the connection unit to the
cutter unit, you cannot move it manually because it is locked. If you try to move forcibly, it
may cause injury.
To Next Page
