6-45
6
Maintenance
R
eplacing the Pinc
h R
oller
s
Replace the pinch roller when it is worn or dirt
y
.
(SP
A-0166: Set of four pinch ro
llers / SP
A-0167: Set of three pinch r
ollers)
1
Remove the O-ring, pinch roller axis, and pinch
roller
.
2
Att
ach a new pinch roller
, and reatt
ach the pinc
h rol
ler axis and O-ring to their original
positions.
Pinch roller ax
is
O-ring
Pinch roller
232
234
