22
Table 6-1 The number of successful reads.
Barcode type
Multiple confirm (m)
m=0
m=1
m=2
m>=3
EAN-13, EAN-8, UPC-A, Code93, China
Post, UK Plessey
2
3
4
m+1
UPC-E, Codabar, Interleaved 2/5, Code39,
Industry2/5, Matrix 2/5, Code11, MSI
Plessey, UPC-E1
3
4
4
m+1
UCC/EAN128, Code128, GS1 DataBar,
GS1 DataBar Limited, GS1 DataBar
Expand, ISBT 128
1
2
3
m+1
Global Max./Min. code length: These two lengths are defined as the valid range of decoded barcode
data length. Make sure that the minimum length setting is no greater than the maximum length setting,
otherwise the labels of the symbol will not be readable. In particular, the same value can be set for both
minimum and maximum reading length to force the fixed length barcode decoded.
Notes:
1. Only set the Max./Min. code length for the specific code type to be zero, can Global Max./Min. code
length be valid.
2. Please refer to the settings of max./min. length for each specific code type in later sections
3. The number of check digits is included in max./min. code length.
4. These two settings have no effect on the symbols with fixed-length, e.g. UPC-A, UPC-E, EAN-13,
EAN-8 and China Post.
Global G1-G4 string selection: The scanner offer one or two string group for all symbols. By setting one
or two digits to indicate which string group you want to apply. You may refer to the chapters of “4-28
G1-G4 & FN1 substitution string setting” and “4-29 G1-G4 string position & Code ID position” .
Example: Group 1 → set 01 or 10. Group 2 and 4 → set 24 or 42.
All valid settings include 00, 01, 02, 03, 04, 10, 11, 12, 13, 14, 20, 21, 22, 23, 24, 30, 31, 32, 33, 34, 40,
41, 42, 43, and 44.
Setting value
Description
00
None
01、10、11
Only Group 1
02、20、22
Only Group 2
03、30、33
Only Group 3
04、40、44
Only Group 4
12、21
Group 1 first, then Group 2
13、31
Group 1 first, then Group 3
14、41
Group 1 first, then Group 4
23、32
Group 2 first, then Group 3
