Mindeo FS580 - Reply_Revision

83
5-8 REPLY_REVISION
Description: Reply to REQUEST_REVISION command with software revision string
Packet Format
Length
Opcode
Status
Revision
Checksum
0x52
Field Descriptions
Field Name
Format
Size
Description
Length
Length of message
(not including checksum).
1 Byte
Length Field
Opcode
0x52
1 Byte
Identifies this opcode type.
Status
Bit 0: Identifies transmit status
Bit 6-1: Unused
Bit 7: Command source
1 Byte
Bit 0:
0=First time packet is sent
1= Subsequent transmission
Bit 7: always be 0(message is from the scanner)
All unused bits recommend to be set to 0.
Revision
ASCII data
variable
Software revision in ASCII (see following for
details).
Checksum
2's complement sum of message
contents excluding checksum.
2 Bytes
Checksum of message.
For example: If the HW/SW_REVISION is “FS580_HW1.0_SW1.0”, the REPLY_REVISION message is:
Length
Opcode
Status
Revision
Checksum
0x16
0x52
0x00
0x46 0x53 0x35 0x38 0x30 0x5F 0x48 0x57 0x31 0x2E 0x30
0x5F 0x53 0x57 0x31 0x2E 0x30 0x20 0x2D
0xFA 0xF0
Host Requirements
None.
Scanner Requirements
The scanner sends its Revision field data string to the host in the following format:
HW/SW_REVISION<space>SCANNER_ID
Resolving:
HW/SW_RIVISION: the version string of hardware and software information.
SCANNER_ID: the ID information of scanner.
Scanner ID Listed:
Scanner ID
Product
Scanner ID
Product
0x2C
FS380
0x1A
ME4144
0x2D
FS580
0x1B
ES4200
0xAB
uE988
0x1C
ES4290
0xAB
uE966
0x3A
ME5110
