Mindeo FS580 - Upc-E1

32
4-9 UPC-E1
Read: Format
System character “1”
Data digits (6 digits)
Check digits
Check digit verification: The check digit verification is optional.
Check digit trans.: By setting Enable, check digit will be transmitted.
Code ID setting: Refer to Code ID setting of “4-7 UPC-A” .
Insertion group selection: Refer to Insertion group selection of “4-7 UPC-A” .
Supplement digits:
Format
System character “1”
Data digits (6 digits)
Check digit
Supplement digits 2 or 5
Truncation/Expansion:
Expand to EAN-13 - It extends to 13-digits with “0” digits when the feature is set to be enabled.
Example: Barcode “11236597”, Output: “0112365000097”.
Expand to UPC-A - It extends to 12-digits when the feature is set to be enabled.
Example: Barcode “11236597”, Output: “112365000097”.
Truncate system character - The system character “1” of UPC-E1 data can be truncated when the
feature is enabled.
Add country code - The country code (“0” for USA) can be added when the feature is enabled.
