Accutorr Plus™ Operating Instructions 0070-10-0692-02 2 - 11
Controls and Indicators Recorder Module
2.4 Recorder Module
FIGURE 2-4 Recorder Module
50. Paper Door
Open this door when loading recorder paper.
51. Paper Tear Edge
The paper tear edge is used to tear off printed recorder strips. The edge can be removed in
the event of a paper jam that needs to be cleared.
50
51
