Mindray BeneHeart D3 User Manual

Defibrillator/Monitor Operator’s Manual 2 - 5
Area 2
(1) Lead Select button
Press this button to select the lead for the first ECG waveform.
(2) Gain select button
Press this button to select the size of the first ECG waveform.
(3) Microphone
It is used for voice recording in AED mode.
(4) NIBP button/Record button
◆ NIBP button (for the equipment configured with NIBP function): press this button
to start or stop NIBP measurements.
◆ Record button (for the equipment without NIBP function): press this button to start
a recording or stop the current recording.
(5) Alarm Pause button
Press this button to pause, reactivate or switch off the alarms.
(6) Mark Event button
Press it to manually mark specified events. If a menu has been open, pressing this button
will close the menu.
(7) Main Menu button
If no menu is displayed on the screen, pressing it will enter the main menu. If there is a
menu displayed, pressing it will close that menu.
(8) Navigation knob
◆ Rotate it clockwise or counterclockwise to move the cursor.
◆ Press it to confirm the selection.
(1)
(4) (5)
(6) (7) (8)
(2)
(3)

Mindray BeneHeart D3 Specifications

General

Type	Defibrillator
Display	Color TFT LCD
Display Size	5.7 inches
Waveform	Biphasic Truncated Exponential (BTE)
Heart Rate Range	15-300 bpm
SpO2 Range	0-100%
NIBP Measurement Method	Oscillometric
Printer Type	Thermal
Paper Width	50 mm
Paper Speed	25 mm/s
IP Rating	IP44
Modes	Manual, AED, Pacing
AED Mode Energy Sequence	150J, 200J
Charging Time	<5 seconds to 200J
Battery Type	Lithium-ion
ECG Monitoring	3-lead
Energy Selection	1-360 J (Manual Mode)
