Mindray DC-8 EXP

Function and Performance Checking Method 5-9
5.4.2.4 Probe Switching
Procedure
Standard
Press <Freeze> key→ connect the probe to the
system→ press <Freeze> key→ press <Probe>
key to select the probe.
Connect a convex probe to probe socket A, and
then connect a linear probe to probe socket B,
the operator can select probe A or probe B as the
active probe.
Press <Freeze> key→ disconnect the probe→
connect another probe to the port
The system can recognize the newly connected
probe in no time.
5.4.2.5 Patient Information Management
Procedure
Standard
Press <Save 1> or <Save 2> (the function
already set) during image scanning
Image will be saved to the patient database, and
a thumbnail will be displayed at the right part of
the screen.
Open [Setup] →[System Preset]→”General”,
then check “Send/Print Image after End Exam”
in the Patient Management area.
Press <End Exam> during image scanning
The system automatically sends the images of
the exam to the default DICOM storage server or
print server.
 Press <Review> key.
 Click [Exit] on the Review screen; or, press
<Review> again, or, press <Esc> key
 The system enters into image review mode.
 The system exits image review mode.
 Click [iVision] on the other menu; or press
user-defined iVision key.
 Select the contents to be demonstrated,
and select the demo mode in the iVision
screen. Then select an item already added
to the list and click [Start]
 When the demonstration is finished, click
[Exit] or press <Esc>.
 Open iVision screen:
 Demonstration begins.
 Image files are played according to file
names one by one (including the image of
system-relevant and PC-compatible format).
 The system exits the demonstration.
Press <iStation> key to enter patient information
management (iStation page)
The saved patient information (images) can be
found, and the patient information can be:
 Backed up/ Restored
 Sent (To DICOM.U disk .etc )
