Measure Preset 2-9
Import/Export an OB GA Table or Formula
1. Select [Import] or [Export] in the Fetal Gestational Age or Fetal Growth page.
2. The system pops up the [Load Data] dialog box.
3. Select the drive and file path the data located.
4. Select the data file to load or export.
5. Click [OK] to confirm.
Tips: only user-defined table that is imported can be exported.
The imported user-defined table of FG and GA has to be *.csv file. The format of the *.csv file is
described as follows:
FG table
Table Type Author Name SD Type Meas Value Unit SD Unit
FG The author
name
Value of standard
deviation
Unit of the
measurement value
Unit of the standard
deviation
Row Num Row number
(N) of the table
No. GA Min Meas Value Max
1 GA value Minimum value Measurement value Maximum value
2
… … … …
… … … … …
N
… … … …
NOTE:
z You should fill in the table according to actual clinical value except those cells with words
in bold.
z Value of standard deviation：
Select from one of the following:
h None
h ±1SD
h ±2SD
h 3%~97%
h 5%~95%
h 10%~90%
z Unit of the measurement value: according to the table to import, select from mm, cm, g, kg,
cm2 or mm2.
z Row number (N) of the table: the maximum row number N in the column of “No.”.
z The third row is empty.
z GA value, Minimum value, Measurement value, Maximum value: input the number of days
without the unit.
To Next Page
