B-2 iScanHelper
You can zoom in a single window in the help information area to see the information. For
details, please refer to “B.4.3 Single/quad-window Display”.
4. Save images as necessary.
5. Press the user-defined key again to exit iScanHelper.
B.4 Basic Screen and Operation
B.4.1 View Selecting Area
Rotate the trackball to move the cursor onto the target view and press <Set>, related
information will be displayed on the help information area.
B.4.2 Help Information Area
Help information area displays on the lower right corner of the screen, providing ultrasonic
image, anatomic graphic, scanning picture and scanning tips.
Ultrasonic image
It is used to compare with images scanned by the operator.
Anatomic graphic
Related anatomical tissue information are provided here.
