Minebea Intec PR 5310/12 - Error Messages; Measuring Circuit and General Errors

11. Error messages | 174
11 Error messages
11.1 Error messages measuring circuit
The internal weighing electronics can generate error messages, which are
shown on the display.
Display Error Possible cause
Error 1 Internal arithmetic overflow
– Faulty calibration values.
Error 2 The measuring signal is higher than
Max + (x d) (Overload)
– Wrong setting.
– Too much weight on the scale.
Error 3 Measuring input open
– The measuring signal is higher than
the permissible range of 36mV.
– Measuring cable is interrupted (cable
break detection).
– Other hardware defect.
Error 4 Value exceeds display The weight value is not displayed:
– Too many digits have been set.
Error 6 No sense voltage
– Load cells not connected.
– Sense line or supply line is interrupted.
– Wrong polarity or sense voltage is low.
Error 7 Negative measuring signal
– Wrong polarity of load cell signal.
– Wrong polarity of load cell supply volt
age.
Error 9 The measuring signal is higher than
the permissible range of 36mV. Can
not read weight values from ADC
(analog-digital converter).
Internal weighing point:
– Error in weighing electronics board.
– Defective load cell.
– Cable break.
