6. Operating | 6.2 - Configuration and adjustment via the keypad | 132
[Timeout] oP 067 tiMout
Automatically exits the setup menu (in weighing mode) after a defined
duration.
Input: 00…59
4. Press "Exit" to exit the setup menu.
5. Save the changes.
6.2.14 Configuring serial interfaces
6.2.14.1 Configuring the serial interface for the printer
1. Press and hold for 2–3 seconds.
SEtuP appears on the display.
2. Press "OK".
Cd 000 appears on the display (Cd flashes).
3. Press (8×) to select SI 070.
4. Press "OK".
PrInt appears on the display.
5. Select the individual parameters and modify if required, see Chapters
Parameter table (setup) and Selecting parameters.
[Interface] Port
Selection: none nonE, RS-232 rS232, RS-485 rS485
[Protocol] ProtoC
Selection: none nonE, RTS/CTS rtS.CtS
[Baud rate] bAud
Baud rate of the data transfer
Selection: 1200, 2400, 4800, 9600 (default), 19200, 38400
[Parity] PArItY
Selection: nonE, odd odd, even EVEn
[Data bits] bItS
Selection: 7, 8
