6. Operating | 6.2 - Configuration and adjustment via the keypad | 122
Condition SPM bit Description
b66 = 1 X66 = 1 Marker bit 3 set, markers are reset after
power on.
6.2.11 Configuring digital outputs
The desired function for output1 to output3 is configured by selecting a
signal from the list.
The output then adopts the corresponding state, see example.
SPM addresses for the digital outputs, see ChapterSystem data.
Selection list for output functions
Function SPM bit Description
b00 = 0 X00 = 0 Digital input 1: inactive
b01 = 0 X01 = 0 Digital input 2: inactive
b02 = 0 X02 = 0 Digital input 3: inactive
b16 = 0 X16 = 0 Limit signal 1: inactive
b17 = 0 X17 = 0 Limit signal 2: inactive
b18 = 0 X18 = 0 Limit signal 3: inactive
b32 = 0 X32 = 0 General error in weighing point: inactive
(no error)
b33 = 0 X33 = 0 Weight above Max: inactive
b34 = 0 X34 = 0 Weight above Max plus overload value: in
active
b35 = 0 X35 = 0 Weight not below zero
b36 = 0 X36 = 0 Weight not within ¼d around zero
b37 = 0 X37 = 0 Weight not in zeroset range
b38 = 0 X38 = 0 Standstill inactive
b39 = 0 X39 = 0 Weight not below zero or above Max
b48 = 0 X48 = 0 For internal use only.
b49 = 0 X49 = 0 For internal use only.
b50 = 0 X50 = 0 Set after power on (= power fail): inactive
b56 = 0 X56 = 0 Analog test not started.
