6. Operating | 6.2 - Configuration and adjustment via the keypad | 123
Function SPM bit Description
b57 = 0 X57 = 0 For internal use only.
b58 = 0 X58 = 0 Indicator not tared.
b64 = 0 X64 = 0 Marker bit 1 not set, markers are reset af
ter power on.
b65 = 0 X65 = 0 Marker bit 2 not set, markers are reset af
ter power on.
b66 = 0 X66 = 0 Marker bit 3 not set, markers are reset af
ter power on.
b00 = 1 X00 = 1 Digital input 1: active
b01 = 1 X01 = 1 Digital input 2: active
b02 = 1 X02 = 1 Digital input 3: active
b16 = 1 X16 = 1 Limit signal 1: active
b17 = 1 X17 = 1 Limit signal 2: active
b18 = 1 X18 = 1 Limit signal 3: active
b32 = 1 X32 = 1 General error in weighing point
b33 = 1 X33 = 1 Weight above Max
b34 = 1 X34 = 1 Weight above Max plus overload value
b35 = 1 X35 = 1 Weight below zero
b36 = 1 X36 = 1 Weight within ¼d around zero
b37 = 1 X37 = 1 Weight in zeroset range
b38 = 1 X38 = 1 Standstill active
b39 = 1 X39 = 1 Weight below zero or above Max
b48 = 1 X48 = 1 For internal use only.
b49 = 1 X49 = 1 For internal use only.
b50 = 1 X50 = 1 Set after power on (= power fail)
b56 = 1 X56 = 1 Analog test started.
b57 = 1 X57 = 1 For internal use only.
b58 = 1 X58 = 1 Indicator is tared.
