6. Operating | 6.2 - Configuration and adjustment via the keypad | 117
6.2.9 Configuring digital inputs
For each of the 3 inputs, an action can be defined for the signal change from
0to1(on) and from 1to0(off), see Chapter Defining actions.
For the signal change from 0to1(on) or from 1to0(off), the selected action
for each digital input can be linked with a condition that must be met. The
condition is selected from the selection list of conditions in ChapterSetting
conditions.
If [no condition] is selected, no condition is agreed. The action is then execut
ed directly.
SPM addresses for the limits, see ChapterSystem data.
Example:
Tare via the digital input only if the gross weight exceeds the limit.
1. Press and hold for 2–3 seconds.
SEtuP appears on the display.
2. Press "OK".
Cd 000 appears on the display (Cd flashes).
Input 1 on
3. Press (4×) to select dI 043.
4. Press "OK".
InP.1on appears on the display.
5. Press "OK".
Ion.ACt appears on the display.
6. Press "OK".
The action for the rising edge of input1 is defined (in this case, if the
input signal changes from 0to1, a tare command is triggered).
no.ACt appears on the display.
7. Press / to select the action b113=1, see Chapter Defining actions.
8. Press "OK".
Ion.Cnd appears on the display.
9. Press "OK".
