6. Operating | 6.2 - Configuration and adjustment via the keypad | 116
[Limit 3 off] LI 035 LIM.3oF
Input: Weight value under 3oF.VAL
Selection: Action under 3oF.ACt, see Chapter Defining actions
Selection: Condition under 3oF.Cnd, see Chapter Setting conditions
5. Press "Exit".
6. Save the settings.
6.2.8.2.1 Defining actions
Markers can be set for all limits (in this case, see Example 2 from Chapter
Configuring limits).
Define the action for the rising edge of the reference signal under
1on.ACt…3on.ACt from the following list (in this case, marker 1 is set if 900kg
is exceeded).
An action for 1oF.ACt…3oF.ACt can be defined accordingly.
Selection list for the actions
Action SPM bit Description
no act --- No function
b64 = 1 X64 = 1 Set marker 1
b65 = 1 X65 = 1 Set marker 2
b66 = 1 X66 = 1 Set marker 3
b64 = 0 X64 = 0 Clear marker 1
b65 = 0 X65 = 0 Clear marker 2
b66 = 0 X66 = 0 Clear marker 3
Note: The limit values can be assigned to the outputs directly in the I/O
parameters.
