4. Device installation | 4.3 - Hardware construction | 36
Technical data
Name Data
Internal connection
Pin strip,
28‑pin
External connection Plug connector, 6-pin
Switch cabinet device: screen connection on
the grounding terminal
Table-top device: screen connection in the
cable gland
Number of channels
6‑wire
or
4‑wire
Load cell supply U
DC
=12V, symmetrical to zero
(U
DC
=±6V, I
max
=160mA)
Capacity (number of load
cells)
≥75Ω, corresponding to 8load cells with
650Ω or 4load cells with 350Ω
Sense input U
DC
=±6V, with monitoring
Measurement input U
DC
=0…36mV, symmetrical to zero
Dead load suppression U
DC
=max.36mV(dead load + range)
Accuracy 0.2µV/d equivalent to 1.2mV for 6000d,
class III; according to OIMLR76/EN45501
Min. measuring signal (OIML) 0.1mV/V=1,2mV equivalent to 0.2µV/d @
6000d
Max. resolution 7.5million internal counts at 3mV/V (max.
3.356mV/V)
Linearity <0.003%
Temperature effect TK
0
<0.05 µV/K RTI,
<0.004%/10K @ 1mV/V
Temperature effect TK
Span
<±4.0ppm/K
Cable length Max. 300m
Cable type
6‑wire
with screen for entire cable and screen
for measurement cables, e.g., PR6135/..
