THE MINELAB EXPLORER
103
USER INFO
7
EXPLORER MODEL FEATURES
Alkaline battery pack Yes Yes
NiMh Battery + Mains Charger No Yes
12volt car charger No Yes
Backlight screen (with backlight button) No Yes
Shortcut buttons 3 4
Coil stand No Yes
Custom select discrimination Yes Yes
Saved Discrim patterns 0 6
Learn Function (accept/reject) No Yes
Edit function targets No Yes
Auto Noise Cancel (scanning) No Yes
Manual Noise Cancel Yes Yes
User saved settings (audio, tones, etc) Current, User A, User B Current, User A, User B
Response Normal, Audio 1,2,3 Normal, Audio 1,2,3
Recovery Selectable (Fast & Deep) Selectable (Fast & Deep)
HARDWARE EXPLORER S* EXPLORER XS
USER FUNCTIONS (SOFTWARE) EXPLORER S* EXPLORER XS
* The Explorer S is Minelab’s base model Explorer detector
EXPLORER MODEL FEATURES
THE MINELAB EXPLORER
102
USER INFO
7
www.minelab.com
Length unextended 43 inches (1100mm)
Length extended 53 inches (1350mm)
Shipping weight 3 lb 8 oz (1740g) excluding batteries
Coil 10.5 inches (264mm). “Double D” waterproof
Audio inputs Internal speaker and headphones
Headphone input inch (3.5mm) 32Ω stereo jack
Transmission Full Band Spectrum. Simultaneous 28 frequency transmission
ranging from 1.5kHz –100kHz
Ground rejection Ground compensation – advanced digital filtering
Discrimination Smartfind™ Two-Dimensional Discrimination
Visual display 64 x 128 pixel liquid crystal display (LCD) control panel
Batteries 8 x 1.5V AA Alkaline cells (not included)
Explorer XS only: 12V, 1500 mAh NiMH sealed battery pack
Optional accessories NiMH battery pack (spare); Car charger; Coil covers;
Mains charger; Transport case
Patents US 4890064, US 5537041, US 5506506
TECHNICAL SPECIFICATIONS FOR THE MINELAB EXPLORER
TECHNICAL SPECIFICATIONS FOR THE MINELAB EXPLORER
