Dimâge Scan Dual II
33
SPECIFTY THE
JOB TYPE/SA
VING
1.
Click on the Scan b
utton to scan.
•
When the 'file sa
ving dialog box' appears
, select the file format
and sav
e the scan.
File f
or
mat:
BMP JPEG,
TIFF (Windows)
PICT
, JPEG,
TIFF (Macintosh)
32
34
