Dimâge Scan Dual II 89
Twain Driver/Plug-in Software
Scan the film according to the Prescan settings.
With the Dimage Scan Dual2 utility software, you can save the final scan in one of the
following file formats.
• JPEG • TIFF
• BMP (Windows only) • PICT (Macintosh operating system only)
The image file of 48 bit (16 bit each RGB) can only be saved in the tiff format.
With the Prescan image displayed in the Prescan tab…
1. Click on in the Main window.
• The final scan will begin.
• When scanning is complete, the final scan will appear in the host applications window.
2. Save the image using the instructions for your host application.
Utility Software
With the Prescan image displayed in the Prescan tab…
1. Click on in the Main window.
2. Enter the desired file name and select the
file destination.
3. Select the file type from the drop-down
list.
4. Click on .
• The final scan will begin.
• When scanning is complete, the scan will be saved in the
selected location. The software will return to the Prescan
tab.
Your system’s standard save dialog box will appear.
3. Close the Control Window to exit the Dimâge Scan Dual2 driver software.
• The driver window will close automatically after each scan if the Close Driver After
Scanning option was selected in the Preferences dialog box (see page 39).
5. Close the Control Window to exit the Dimâge Scan
Dual2 driver software.
• The driver window will close automatically after each scan
if the Close Driver After Scanning option was selected in
the Preferences dialog box (see page 39).
FINAL SCAN
