FX-350/351 Series Programming Manual
11
sub menu categories, the configuration allows full front panel configuration of the system and the operation menu
performs certain operations which may not be possible using the common control switches and indicators on the
front panel.
CONFIGURATION MENU
The configuration menu is divided into the following sub menu items:
The “4. Dialer config” menu will only appear if there is a UDACT on-board.
CONFIGURATION MENU/PANEL CONFIGURATION
The panel configuration is further sub divided into the following sub menus
PANEL CONFIGURATION/1. FEATURES
The features described are the overall features of the system and their impact is system wide. The default setting in
some features is shown as selected.
Panel Configuration/Features/Manual Signal Silence
The manual signal silence option will allow silencing of the signal, from the common control signal silence switch,
when they are active.
Panel Configuration/Features/Fire Drill
This function is used to enable/disable fire drill operation from the fire common control fire drill switch at the front
panel.
Panel Configuration/Features/waterflow retard operation
If disabled, all the initiating circuits configured as waterflow act as non-verified alarms. If enabled, retard operation is
performed for initiating circuits configured as waterflow. Default is disabled.
---- Command Menu ---
1. Configuration
2. Operation
---Configuration ---
1. Panel config .
2. Auto config .
3. Dflt . config .
4. Dialer config .
5. Time config .
6. Afthrs config .
---Panel config -----
1. Features
2. Devices
3. Correlation
4. Groups
5. Remote Sw
0DQXDO6LJQDO6LO
>;@(QDEOHG
)LUH'ULOO
>;@(QDEOHG
:DWHUIORZ5HWDUG
> @(QDEOHG
To Next Page
