FX-350/351 Series Programming Manual
15
Panel Configuration/Features/Display adders (For FX-351 Model only)
This feature selects the number of RAX-332 present in the system, by default one is always present.
Panel Configuration/Features/Agency selection
This feature selects the agency having jurisdiction for the panel.
PANEL CONFIGURATION/2. DEVICES CONFIGURATION
The device configuration is divided into 6 sub menu items. The user is asked to enter the loop number and the
device address to proceed with the device configuration.
Use # key to move to the Device Address position.
If the device is not already configured the next screen will prompt the user for adding the new device
After the confirmation the following options are available for configuring a device.
Panel Configuration/Devices/1. Device type
The following selection is available for the devices. This selection includes both the input and output devices.
Panel Configuration/Devices/2. Sensitivity
This option will set the sensitivity for the ion, photo multi-sensor and thermal for the normal and off-hours time. The
sensitivity of the sensors can be set to full range depending upon the agency selection.
If UL or ULC is selected, the following range of sensitivity in %/ft obscurity is available for both the normal and off-
Display adder cards
[X] 1
[ ] 2
Jurisdiction
[ ] ULI
[X] ULC
Device address
Loop :__ DevAddr :___
Add Circuit ?Y/N
'HYLFHV
'HYLFHW\SH
6HFRQGVWDJH
6HQVLWLYLW\
3URFHVVW\SH
6LOHQFH DEOH
/DEHO
'HYLFHW\SH
,RQ
3KRWR
7KHUPDO
0XOWLVHQVRU
&RQWDFW
&RQWDFWPLQL
6SY 2SW
5HOD\
Sensitivity
1. Normal
2. Off hours
