Command Mode - Configuration & Operation
18
After the confirmation the user is prompted for entering the output device. The circuits are recognized by the Loop#
and the device address as shown below
After the device is added the list is updated and the user can add more devices to the list or press the CANCEL key
to go back to the previous menu.
PANEL CONFIGURATION/4. GROUPS
Panel Configuration/Groups/1. LED Groups
The LED groups are used to map a number of similar process type inputs and/or outputs to LEDs on a RAX-332
adder modules. Each RAX-332 has 32 LED zones and a maximum of two RAX-332 are allowed per fire alarm. The
LED zone mapping is achieved by creating a group of either input or output circuits with the same basic process
types such as alarm, supervisory, trouble, monitor and signal. The group is then assigned to an LED zone on the
RAX-332 display adder.
Note: An LED zone consists of two LEDs, one dual color (red/amber) for annunciating alarm/supervisory condition
and the other is amber for annunciating trouble condition.
If there are no LED groups configured the following message is displayed is:
If there are LED groups already configured the list of all the configured groups is shown in the following format.
Sixty-four LED groups are available. There is a label associated with each LED group and the groups are solely
recognized by its label.
The user can press RIGHT arrow key to add and LEFT arrow key to delete a group. When a user deleted a group
after the confirmation, the group is deleted and the list is updated. When the user adds a group an empty group is
created with group type defaulted as alarm.
To configure an LED group the user can press the ENTER key with the group selected on the second line of the
display. The following options are available to configure an LED group.
Here the basic process type of the group is selected and if the group is selected of a certain process type then only
circuits with that process type can be added to the group. The following list shows the type of the group that can be
Add Correlation
Yes/No
Opt Dev Loop # & Addr
Loop :__ DevAddr :___
------ Groups --------
1. Led Groups
2. Rem Led Groups
3. Bypass Groups
---- LED Groups -----
No LED groups
---- LED Groups----
LED Floor A
LED Floor B
LED Floor C
----
LED Groups
----
1. Type
2 . Group members
3 . Led map
4.
Label
