FX-350/351 Series Programming Manual
19
selected. Item 1 to 4 is dedicated to input circuits and items 5 and 6 are dedicated to output circuits.
Selecting the group members shows the list of all the group members of the group. The members/circuits are
recognized by the Loop# and the device address
The user can press RIGHT arrow key to add and LEFT arrow key to delete a group member. When a user deleted
a group member after the confirmation, the group member is deleted and the list is updated. When the user adds a
group member the user is prompted to add a member/circuit.
After the circuit is added the list is updated and re-displayed on the shared display
Selecting LED map will allow the user to assign the group a zone LED on the RAX-332. LEDs are numbered from 1
to 32 for the first RAX-332 and from 33 to 64 for the second and last RAX-332. The user is prompted to enter the
zone LED no as shown below.
Panel Configuration/Groups/2. Remote LED Groups
Remote LED groups are used to map the remote LED annunciator’s LEDs to a group of input and/or output circuits.
There is a maximum of 200 LED zones available that can be mapped to remote LED groups and the maximum
number of remote LED groups that can be created is 130.
The remote LED zone mapping is carried out by creating a group of either input or output circuits with the same
basic process type of alarm, supervisory, trouble, monitor and signal. The group is then assigned to an LED zone
on the remote LED annunciator.
The mapping is duplicated to multiple LED annunciators if added.
If there are no Remote LED groups configured the following message is displayed.
If there are Remote LED groups already configured the list of all the configured groups is shown in the following
format.
Note: When using an SRM-312 Smart Relay module, the relays must be mapped to the first 12 (or less if
not using all the relays) remote LEDs..
------
Type -------
1. Alarm
2 . Supervisory
3 . Monitor
4 . Trouble
5 . Signal
6 . Relay
---Group members ---
Lp:01 DevAddr :006
Lp:01 DevAddr :008
Lp:01 DevAddr :010
Dev Loop # & Addr
Loop :__ DevAddr :___
------ Led map ------
Zone Led No :__
---Rem LED Groups --
No Rem LED groups
--
Rem LED Groups
--
Rem LED Floor A
Rem LED Floor B
Rem LED Floor C
