Command Mode - Configuration & Operation
20
There is label associated with each remote LED group and the groups are solely recognized by its label, such as
“Floor A”.
The user can press RIGHT arrow key to add and LEFT arrow key to delete a group. When a user deleted a group
after the confirmation, the group is deleted and the list is updated. When the user adds a group an empty group is
created with group type defaulted as alarm
To configure a remote LED group the user can press the ENTER key with the group selected on the second line of
the display. The following options are available to configure a remote LED group.
Here the basic process type of the group is selected and if the group is selected of a certain process type then only
circuits with that process type can be added to the group. The following list shows the type of the group that can be
selected. Item 1 to 4 is dedicated to input circuits and the items 5 and 6 are dedicated to output circuits.
Selecting the group members shows the list of all the group members of the group. The members/circuits are
recognized by the Loop# and the device address
The user can press RIGHT arrow key to add and LEFT arrow key to delete a group member. When a user deleted a
group member after the confirmation, the group member is deleted and the list is updated. When the user adds a
group member the user is prompted to add a member/circuit.
After the circuit is added the list is updated and re-displayed on the shared display
Selecting LED map will allow the user to assign the group a zone LED on the remote LED annunciator. LEDs are
numbered from 1 to 200. The user is prompted to enter the zone LED no as shown below.
Panel Configuration/Groups/3. Bypass Groups
Bypass groups are used to bypass a group of circuits, input circuits, output circuits or a combination, by using
control command using the shared display and the keypad.
The bypass groups can be mapped to RAX-332 zone LEDs and cannot be mapped to remote LED annunciators
zone LEDs.
If there are no bypass groups configured the following message is displayed.
----
LED Groups
----
1. Type
2 . Group members
3 . Led map
4.
Label
------
Type -------
1. Alarm
2 . Supervisory
3 . Monitor
4 . Trouble
5 . Signal
6 . Relay
---Group members ---
Lp:01 DevAddr :006
Lp:01 DevAddr :008
Lp:01 DevAddr :010
Dev Loop # & Addr
Loop :__ DevAddr :___
------ Led map ------
Zone Led No :__
