FX-350/351 Series Programming Manual
21
If there are bypass groups already configured the list of all the configured groups is shown in the following format.
There is a label (which must be entered) associated with each bypass group and the groups are solely recognized
by its label, such as “Floor A”. Fourteen characters are allowed for each label. The label is fully editable and should
be selected as a meaningful reference to the group.
The user can press RIGHT arrow key to add and LEFT arrow key to delete a group. When a user deletes a group,
after the confirmation, the group is deleted and the list is updated. When the user adds a group an empty group is
created.
To configure a bypass group the user can press the ENTER key with the group selected on the second line of the
display. The following options are available to configure a bypass group.
Selecting the input circuits shows the list of all the input circuits of the group. The circuits are recognized by the
Loop# and the device address as shown below
The user can press RIGHT arrow key to add and LEFT arrow key to delete an input circuit. When a user deletes an
input circuit, after the confirmation, the circuit is deleted and the list is updated. When the user adds an input circuit
the user is prompted to add an input circuit.
After the circuit is added the list is updated and re-displayed on the shared display
Selecting the output circuits shows the list of all the output circuits of the group. The circuits are recognized by the
Loop# and the device address as shown below
The user can press RIGHT arrow key to add and LEFT arrow key to delete an output circuit. When a user deleted
an output circuit, after the confirmation, the circuit is deleted and the list is updated. When the user adds an output
circuit the user is prompted to add an output circuit.
After the circuit is added the list is updated and re-displayed on the shared display.
Selecting LED map will allow the user to assign the bypass group a zone LED on the RAX-332. LEDs are
numbered from 1 to 32 for the first RAX-332 and from 33 to 64 for the second and last RAX-332. The user is
---Bypass groups ---
No bypass groups
--- Bypass groups---
1. Bypass Floor A
2. Bypass Floor B
3. Bypass Floor C
--- Bypass groups ---
1 . Input circuits
2. Output circuits
3 . Led map
4 . Label
---Input circuits ---
Lp:01 DevAddr :006
Lp:01 DevAddr :008
Lp:01 DevAddr :010
Ipt Dev Loop # & Addr
Loop :__ DevAddr :___
--Output circuits ---
Lp:01 DevAddr :006
Lp:01 DevAddr :008
Lp:01 DevAddr :010
Opt Dev Loop # & Addr
Loop :__ DevAddr :___
