FX-350/351 Series Programming Manual
13
Panel Configuration/Features/Power fail timer
This feature allows a programmed delay before the AC fail trouble is transmitted by the optional PR-300
. (Note:
the delay for transmission by the dialer is configured under Dialer Configuration – Item 4 –Time Parameters - AC
Loss Delay)
Panel Configuration/Features/Common supervisory relay
This feature is used to make the common supervisory relay acts as a common alarm relay if enabled. Default is
disabled
Panel Configuration/Features/Signal silence isolator
This feature makes the system aware that the isolators are present on the main panel powered output circuits if
enabled. Default is disabled.
Panel Configuration/Features/Strobe types
Select the strobe manufacturer for synchronous strobes. Synchronous strobes are driven by following a different
ON/OFF pattern depending on the manufacturer’s specification. Normal means the strobes are not synchronized
and when the circuit gets active it is turned ON steady. This feature applies to the main panel powered output
circuits, configured as strobes, only.
Panel Configuration/Features/Evacuation code
Select the evacuation code for the 2nd stage in a two stage system and for the 1st stage in a single stage system.
Panel Configuration/Features/Monitor alert
Note: Once a specific type of strobe is selected, for example Mircom, then only this type of strobe is allowed
for the entire system.
$&SZUIDLOGO\WPU
>;@ 1RQH
>@ +U
> @+UV
>@ +UV
&RPPRQVXSY UHOD\
>@ (QDEOHG
6LJVLO LVRODWRU
>@ (QDEOHG
Strobes type
[X] Normal
[ ] Gentex
[ ] System Sensor
[ ] Mircom
[ ] Faraday
[ ] Wheelock
Evacuation code
[ ] Continuous
[ ] March Time
[X] Temporal
[ ] California
0RQLWRUDOHUW
>@ (QDEOHG
