Appendix-642 Spline interpolation
7Appendix
Fig.7-53:Inserting path point data
At this time, the default values of the path point data inserted before the selected path point data line will be
the values shown in Table 7-13.
Table 7-13:Default values of inserted path point data
Selected line Default value of path point data
Head line The same values as Table 7-12 "Default value when newly added" are applied.
Other than head line Position X to L2 The average value of the path point data on the line before the selected
path point data.
FLG1, FLG2 Same value as selected path point data.
Other than
position
The same values as Table 7-12 "Default value when newly added" are applied.
[Insert]
