7Appendix
Spline interpolation Appendix-647
■Ex-T control settings
Specify "Ex-T control settings" for spline interpolation.
By clicking [Tool] → [Ex-T control settings] on the menu, the content of Ex-T control settings set to the spline
file at the active spline file editing screen is displayed in the settings screen.
Fig.7-61:Ex-T control settings screen
■Entering a comment
A comment can be entered for the spline file. The details entered for the comment are displayed in the Com-
ments filed of the spline file list. Make it easier to select the spline file by entering the work details or condi-
tions, etc., as a comment.
When the menu [File]
→ [Properties] is clicked, the comment entered in the spline file on the active Spline
File Edit screen appears on the Property screen.
Fig.7-62:Property screen
Up to 192 characters can be entered for the comment. Note that a Line Return cannot be entered. The
default state is blank.
When the comment is entered and the [OK] button is clicked, the details are saved and the Property screen
will close. If the [Cancel] button is clicked, the Property screen will close without saving the entered com-
ment.
Ex-T control setting is valid. Ex-T control setting is invalid.
