Annex Dimensions
SD-/SQ series A - 11
The following figure shows the external dimensions and the range of motion of robot arms
RH-12SDH5535 and RH-12SQH5535
.
R001414E
Fig. A-11:
External dimensions and range of motion of robot arms RH-12SDH5535 and RH-12SQH5535
All dimensions in mm
Limits of
range of motion
View A
Installation
surface
Weight: 41 kg
