Annex Dimensions
SD-/SQ series A - 13
The following figure shows the external dimensions and the range of motion of robot arms
RH-12SDH8535 and RH-12SQH8535
.
R001392E
Fig. A-13:
External dimensions and range of motion of robot arms RH-12SDH8535
and
RH-12SQH8535
All dimensions in mm
View A
Installation
surface
Weight: 45 kg
