(3) QnUDVCPU, QnUDPVCPU
Classification Type Name
Default
Parameter-
set range
Reference
Point Range
Internal user
device
Bit
device
Input 8192 X0 to X1FFF Hexadecimal
Can be
changed.
*3
Page 346,
Section 4.2.1
Output 8192 Y0 to Y1FFF Hexadecimal
Page 348,
Section 4.2.2
Internal relay
28672
*7
M0 to M28672
*8
Decimal
Page 349,
Section 4.2.3
Latch relay 8192 L0 to L8191 Decimal
Page 350,
Section 4.2.4
Annunciator 2048 F0 to F2047 Decimal
Page 351,
Section 4.2.5
Edge relay 2048 V0 to V2047 Decimal
Page 355,
Section 4.2.6
Step relay 8192 S0 to S8191 Decimal
Page 358,
Section 4.2.9
Link relay 8192 B0 to B1FFF Hexadecimal
Page 356,
Section 4.2.7
Link special relay 2048 SB0 to SB7FF Hexadecimal
Page 357,
Section 4.2.8
Word
device
Timer
*1
2048 T0 to T2047 Decimal
Page 358,
Section 4.2.10
Retentive timer
*1
0 (ST0 to ST2047) Decimal
Counter
*1
1024 C0 to C1023 Decimal
Page 367,
Section 4.2.11
Data register
41984
*9
D0 to D41983
*10
Decimal
Page 371,
Section 4.2.12
Link register 8192 W0 to W1FFF Hexadecimal
Page 372,
Section 4.2.13
Link special
register
2048 SW0 to SW7FF Hexadecimal
Page 374,
Section 4.2.14
Internal system
device
Bit
device
Function input 16 FX0 to FXF Hexadecimal
Cannot be
changed.
Page 375,
Section 4.3.1
Function output 16 FY0 to FYF Hexadecimal
Page 375,
Section 4.3.1
Special relay 2048 SM0 to SM2047 Decimal
Page 377,
Section 4.3.2
Word
device
Function register 5 FD0 to FD4 Decimal
Page 375,
Section 4.3.1
Special register 2048 SD0 to SD2047 Decimal
Page 377,
Section 4.3.3
Link direct device
Bit
device
Link input 16384 Jn\X0 to Jn\X3FFF Hexadecimal
Cannot be
changed.
Page 378,
Section 4.4
Link output 16384 Jn\Y0 to Jn\Y3FFF Hexadecimal
Link relay 32768 Jn\B0 to Jn\B7FFF Hexadecimal
Link special relay 512 Jn\SB0 to Jn\S1FF Hexadecimal
Word
device
Link register 131072 Jn\W0 to Jn\W1FFFF Hexadecimal
Link special
register
512 Jn\SW0 to Jn\SW1FF Hexadecimal
