CHAPTER 6 CONVENIENT USAGE OF DEVICES
6
6.2 Local Device
(b) Setting the drive and file name
After setting the local device range, set a memory for storing the local device file and a file name in the PLC file
tab of the PLC parameter dialog box.
(c) Writing the setting data
Write the data set in (a) and (b) to the CPU module.
[Online] [Write to PLC]
● If the size setting of the local device in the standard RAM is changed with a sampling trace file stored in the standard
RAM, the sampling trace file is cleared. To save the trace results in your personal computer, perform the following
operations.
[Debug] [Sampling Trace] [Read from PLC]
● All devices that are not set as local devices are global devices.
