476
(e) Auto refresh with an intelligent function module
This is the time required for refreshing data between the buffer memory of an intelligent function module and
devices in the CPU module.
Calculation method
Calculate using the following formulas. Use the values in the following tables for KN1 and KN2.
(Refresh time) = KN1 + KN2 × (number of refresh points)
When the number of auto refresh points for the analog-digital converter module (Q64AD) is 4 points
(when the module is mounted on the Q26UDHCPU main base unit)
(5) Function execution time in END processing
This is the time required for updating calendar or clearing error in END processing.
(a) Calendar update
The following processing time is required to change or read the clock data when the clock data set request
(SM210 changes from off to on) or the clock data read request (SM213 turns on) is issued.
CPU module
When an intelligent function
module is mounted on the
main base unit
When an intelligent function
module is mounted on the
extension base unit
KN1 KN2 KN1 KN2
Q00UJCPU 96.3µs 6.7µs 79.7µs 8.9µs
Q00UCPU, Q01UCPU 96.3µs 6.7µs 79.7µs 8.1µs
Q02UCPU 23µs 6.0µs 45µs 7.0µs
Q03UD(E)CPU 6.0µs 5.0µs 7.0µs 6.0µs
Q03UDVCPU, Q04UD(E)HCPU, Q04UDVCPU,
Q04UDPVCPU, Q06UD(E)HCPU, Q06UDVCPU,
Q06UDPVCPU, Q10UD(E)HCPU, Q13UD(E)HCPU,
Q13UDVCPU, Q13UDPVCPU, Q20UD(E)HCPU,
Q26UD(E)HCPU, Q26UDVCPU, Q26UDPVCPU,
Q50UDEHCPU, Q100UDEHCPU
4.0µs 5.0µs 5.0µs 6.0µs
0.024 (ms) = 0.004 + 0.005 × 4
CPU module
Processing time in END processing
When the clock data set
request is issued
When the clock data
read request is issued
Q00UJCPU, Q00UCPU, Q01UCPU 0.028ms 0.017ms
Q02UCPU 0.027ms 0.013ms
Q03UD(E)CPU, Q04UD(E)HCPU, Q06UD(E)HCPU, Q10UD(E)HCPU,
Q13UD(E)HCPU, Q20UD(E)HCPU, Q26UD(E)HCPU, Q50UDEHCPU,
Q100UDEHCPU
0.011ms 0.004ms
Q03UDVCPU, Q04UDVCPU, Q04UDPVCPU, Q06UDVCPU,
Q06UDPVCPU, Q13UDVCPU, Q13UDPVCPU,Q26UDVCPU,
Q26UDPVCPU
0.011ms 0.007ms
